OUR PRODUCTS

Rated Voltage : 220 - 300kV 40/50kA 50Hz
Rated Current : 3150A/ 4000A

Features:-
• Single phase in one enclosure
• Individual phase operating mechanism
• Single bus or double bus
• Motorized spring operating mechanism

Rated Voltage : 110 - 145kV 40kA 50Hz
Rated Current : 2000A/ 3150A

Features:-
• Three phase in one enclosure
• Common operating mechanism
• Single bus or double bus
• Motorized spring operating mechanism

Rated Voltage : 145kV 31.5/40kA 50Hz
Rated Current : 3150A

Features:-
• Common Operating mechanism
• Motorized spring operating mechanism
• Single break SF6 puffer
Call Us Email

Rated Voltage : 145kV /170kV 40kA
Rated Current : 3150A , 1600A

Features:-
• Common Operating mechanism
• Integrated earthing switch
• Motorized operating mechanism
• Horizontal centre break

Rated Voltage : 11kV / 33kV
Rated Current : 2000A/2500A 50/60 Hz

Features:-
• Short-circuit current: up to 25/31.5 kA (1-3 s)
• Internal arc classification: IAC AFL(R)
• Standards and certifications: IEC

SCADA Equipped / Ready
11/0.433kV (500kVA & 1000kVA)

Features:-
• RMU 12kV, 630A (Feeder) 200 A (Tx Feeder)
• 11/0.433 kV 500kVA & 1000kVA LVDB
• DIN Type Fuse Switch 1600A & 800A
• Fuse NH2, DIN type CSRTU

Features:-
• Configuration : 2K1TS, 2K2TS, 3K1TS, 3K
• I max (Outgoing) : Up to 630A
• I max (Incoming) : Up to 200A
• Internal Arc : 20kA, 1 sec

Space Saving:-
• Simplified and time saving on civil work
• Customizable design to meet with various customer specification and site conditions
• 30% compared to the conventional substation design
• Time saving of 30% on site installation with the pre-fab substation Single lift steel frame design

End-to-end EPCC solutions from design to commissioning. Complete project management for seamless execution and delivery.

Key Services:-
• Transmission lines
• Substations
• Feeder Stations
• EV Installation

Interconnection Facilities

Seamless grid connection solutions for power plants and substations. Expert design and implementation for reliable grid integration.

EV Solutions

Advanced EV charging solutions for commercial and public use. Fast, safe, and smart charging technology for the future of mobility.

Others

• Other products and services include:-
• RCB
• Feederpillar
